ARK-2000 Auto Refractometer With Corneal Curvature

sku:

Features :

• Three kinds of measurement model is optional. With corneal curvature and dioptre measurement function

• Most each record 10 times, automatic display representative value

• Intuitive interface, convenient adjustment, the VD value, the precision and print mode, etc

• Automatic mist target, eff ectively reduce the measurement error caused by adjusting

• One key lock function, Convenient and practical

• Fast thermal printer

Category	Parameter	Specification
Measurement Mode	K/R mode	Refractive and Keratometer measurement.
	REF mode	Refractive measurement
	KEF mode	Corneal curvature measurement
Refractive Measurement	Vertex Distance	0.0, 12.0, 13.75, 15.0 mm
	Sphere	-20.00 ~ +20.00 D (0.12 / 0.25 D step) V(D=12mm)
	Cylinder	0.00 ~ ±10.00 D (0.12 / 0.25 D step)
	Axis	1° ~ 180° (1° step)
	Pupil Distance	30 ~ 85 mm
	Min. pupil diameter measurable	≤ 2.0 mm
	Target	Automatic fogging target
Corneal Curvature Measurement	Radius of curvature	5 ~ 10 mm (0.01 mm step)
	Corneal Refraction	33.00 ~ 67.00 D (0.12 / 0.25 D step)
	Corneal Astigmatism	0.00 ~ -15.00 D (0.12 / 0.25 D step)
	Angle of corneal	1° ~ 180° (1° step)
	Corneal diameter	2.0 ~ 12.00 mm
Hardware Specification	Monitor	5.7 inch Color LCD
	Printer	Fast thermal printer
	Power saving function	OFF, 5, 15 mins (selectable)
	Power supply	AC 110~220 V, 50/60 Hz
	Dimensions / Weight	288(W) × 500(D) × 480(H) mm / 14 kg
