Specifications:
Microscope | Microscope Type | Converging Stereoscope |
Magnifications | 2 Steps magnifications | |
Eyepiece | 10x | |
Magnification Ratio (Field of View) | 16×（φ14.5mm）、10×（φ18） | |
PD adjustment | 50mm ~ 82mm | |
Diopter adjustment | +5D ~ -5D | |
Base | Side Shift | 110mm |
Depth Shift | 90mm | |
Height Shift | 30mm | |
Chin rest | Height Shift | 80mm |
Fixation Target | Red LED | |
Property of illumination | Slit width | 0 ~ 9mm continuous(at9mm, slit becomes circle) |
Slit height | 1 ~ 8mm continuous | |
Slit angle Light spot diameter | 0~ 1800 Adjustable Ф9 、Ф8、 Ф5 、 Ф3,Ф2 、Ф1 、Ф0.2mm | |
Filter | Heat absorption ,Grey ,Red-free ,Cobalt Blue | |
Illumination Bulb | 12V 50W halogen lamp |
