The AL-360 auto lensmeter is a compact and lightweight auto lensmeter designed for quick and accurate lens measurements. It features a 5.6-inch tilting TFT color LCD touch screen for clear viewing and easy operation.
The device includes a built-in thermal printer and UV tester, measures pupil distance (PD), and automatically recognizes single and progressive lenses. Measurement data can be displayed on a computer, and the memory function allows storing results for convenient reference.
Measure Scope | |
| Sphere | 0~±25D 0.01/0.12/0.25D steps |
| Cylinder | 0~±9.99D 0.01/0.12/0.25D steps |
| Axis | 0°~180° (1°step) |
| ADD | 0~+9.99D 0.01/0.12/0.25D steps |
| Prism degree | 0~15 Δ 0.01/0.12/0.25 Δ steps |
| Mode | |
| Cylinder | +,+/-,- |
| Contact lens | soft/hard |
| Prism | X-Y, P-B |
| Measuring mode | Single/progressive/ automatic recognition contact lens |
| Others | |
| Diameter of lens | Ø 20~108mm |
| PD | 45~90mm, 0.25mm steps |
| Speed | 0.1S |
| Display | TFT LCD(5.6") |
| Printer | Thermal printer |
| Dimensions | 222*320*360mm |
| Wight | 5kg |
| Power supply | 110/220V/50HZ/60HZ |
