Portable Ophthalmic Microscope Auto Zoom Magnification Surgical Microscope 5.01 Reviews

sku:1000 set/month

Portable Ophthalmic Microscope Auto Zoom Magnification Surgical Microscope


1. Wide field of view, strong stereoscopic and good depth of field.

2. Coaxial illumination, imported bulbs and optical fiber, design in cold light source and strong light intensity.

3. Japanese imported zoom equipment with low-noise, high-accuracy and in good control.

4. Foot switch of Japanese OMRON and conveniently in operating.

5. Brand new design, operation and installation easily.

6. Portable surgical microscope, convenient for assembly and transportation.

7. Binocular/ Monocular assistant microscope are optional.

Description


Microscope
Item
Specification

Eyepiece
10X wide field

Observation Angle
45°

Pupil distance
50-76mm

Diopter Adjustment
±5D(binocular)

Objective
φ45mm

Magnification
4X- 20X continually motorized zoom

Field of View
8mm65mm

Working Distance
≥170mm

Focus Adjustment
±20mm foot control
IIIumination
Light Source
15V/150W Halogen Lamp or LED Light
Intensity
≥60,000Lux

Type
Optical Fiber

Control
Stepless Control
Base
Length of Arm Extended
840mm
Elevation
±100mm
Power
~220V,50Hz
Foot Switch
Motorized Focus and Zoom




1.Independent coaxial stereo assiatant microscope

2.Aspheric designed condenser lens for better red reflex 3.Better red reflection, safer surgery
4. Multi-function foot switch for easy control5.Halogen Lamp or LED Light
