Sphere | -19.00~+16.75D(0.25D/0.50D/1.00D/3.00D steps) |
Cylinder | -6.00D~+6.00D 0.25D steps |
Axis angle | 0~180°(1°/5°steps) |
Pupil distance | Distant range :52~80mm Close range :48~76mm 0.5/1mm steps |
Rotary Prism | 0~20(0.1/0.5/1 steps) |
Cross Cylinder Lens | ±0.25D |
Retinoscope | +1.50D(67cm),+2.00D(50cm) |
Auxiliary Lens | PH, Binoculus(1.0mm) |
RMV/RMH | |
RL(Right eye),GL(Left eye) | |
Polaroid(Right eye 135°/45°),(Left eye 45°/135°) | |
Prism(Right 3 BU ,6 BU),(Left 3 BD, 10 BI) | |
Cross Cylinder Lens(±0.50D Axis=90°) | |
PD Lens | |
CV head size | 381mm×286mm×111mm 3.8kg |
Table size | 243mm×171mm×7mm 0.5kg |
Power supply | AC220V 50Hz or AC110V 60Hz,90W |
